Static, Dynamic, Hydraulic and Pneumatic Seals

Sizonke Trading offers a range of seals for fluid power (hydraulic) or pneumatic applications made from high-performance polymer materials for use in standard to critical applications where improved performance, longer seal life and cost saving is required. Custom made for your equipment from 6mm to 2000 mm and bigger – O-rings form 3 mm to 2500 mm.

Our flagship material

FDA approved

IST
IST seals

Materials

Our team of highly trained and experienced engineers and machinist guarantee that the product we supply are of the highest quality and standard .

We make use of our own uniquely  engineered materials allowing us to seal better for longer and all other standard materials are sourced from world class manufactures to ensure we have tractability and control over the quality of these materials.

Specialized, proprietary materials from IST

ISM 10

Colour: Gray
Feature: Internally lubricated
Hardness: 95 Shore A
Temp: -30 to 110 °C

ISM 11

Colour: Orange
Feature: soft &  Internally lubricated
Hardness: 85 Shore A
Temp: -40 to 100 °C

ISM 12

Colour: Dark Orange
Feature: High Temp Internally lubricated
Hardness: 95 Shore A
Temp: -30 to 135 °C

ISM 13

Colour: Dark Blue
Feature: Low Temp Internally lubricated
Hardness: 95 Shore A
Temp: -50 to 105 °C

Hydraulic and Pneumatic seals materials

Industrial grade elastomer materials

HPU, FDA HPU, NBR 85, NBR 95, NBR FDA, EPDM, EPDM FDA, FPM, AFLAS,Silicon

PTFE blended materials

Bronze, Carbon, Glass Fiber, Polyimid

Engineered plastic materials

POM, Nylon, Peek , PE-UHMW

Sealing Profiles Hydraulic and Pneumatic seals

Our specially engineered standard profile are designed to seal most of application however they can be adapted or modified to suit a special application.

Rod sealing profiles

Rod seal Profile - Sizonke trading

Piston Sealing profiles

Piston seal Profile - Sizonke Trading.pn

Rotary Sealing profiles

Rotary seal Profile - - Sizonke trading.

Wiper Sealing profiles

Wiper Profile - - Sizonke Trading

Static Sealing profiles

Static seals profile - Sizonke trading.p

Guide Rings or Wear band  profiles

Guide Rings- - Sizonke trading
